Fixation models

A fixation model takes two fitness values, f_i (source) and f_j (target), and returns the probability that an organism with fitness f_j displaces one with fitness f_i in some population model. gpgraph-v2 ships four canonical models and accepts user callables.

All four built-in models accept either scalar or matching array inputs. The array path is what add_model uses to populate the entire edge set in a single numpy pass.

The four fixation models compared as fixation probability versus fitness ratio The four fixation models compared as fixation probability versus fitness ratio

Each model maps a source/target fitness pair to a fixation probability with a different shape: SSWM is a sharp threshold, Moran and McCandlish are smoother, and the ratio model is the simplest. Picking one sets how strongly the resulting edge weights favor uphill moves.

strong_selection_weak_mutation

Gillespie (1984). Probability of fixation in the strong-selection weak-mutation limit:

\[ \pi_{i \to j} \;=\; 1 - \exp(-s_{ij}), \qquad s_{ij} \;=\; \frac{f_j - f_i}{f_i} \]

For \(f_j \le f_i\), returns 0 (no advantageous fixation).

from gpgraph.fixation import strong_selection_weak_mutation

strong_selection_weak_mutation(1.0, 1.1)  # 0.0952

The string alias is "sswm":

G.add_model(column="phenotypes", model="sswm")

This is the default choice for most analyses. It is parameter-free and has a clean interpretation: each edge prob is the fixation probability of the target mutation given the source.

ratio

\[ \operatorname{ratio}(f_i, f_j) \;=\; \frac{f_j}{f_i} \]

Not a probability, just the relative fitness. Useful when you want edge weights that grow without bound rather than saturate.

from gpgraph.fixation import ratio

ratio(1.0, 2.0)  # 2.0

The string alias is "ratio".

Not a probability

ratio is not in [0, 1] for f_j > f_i. Treat the resulting prob edge attribute as a relative-flow weight, not a probability mass.

moran

Sella and Hirsch (2005). Moran-process fixation probability for population size \(N\):

\[ \pi_{i \to j} \;=\; \frac{1 - f_i / f_j}{1 - (f_i / f_j)^{N}} \]

with overflow-protected branches preserving the scalar v1 behavior. For \(f_i = f_j\), returns \(1/N\) via a two-point average of slightly perturbed evaluations (matches v1).

from gpgraph.fixation import moran

moran(1.0, 1.01, population_size=100)  # ~0.0179

The string alias is "moran". Requires population_size=N as a keyword:

G.add_model(column="phenotypes", model="moran", population_size=100)

For N == 1, returns 1.0 by convention (matches v1).

mcclandish

McCandlish (2011). An exponentiated form of the Moran probability:

\[ \pi_{i \to j} \;=\; \frac{1 - \exp\!\bigl(-2(f_j - f_i)\bigr)}{1 - \exp\!\bigl(-2 N (f_j - f_i)\bigr)} \]

with the same overflow-protected branches and \(f_i = f_j\) handling as moran.

from gpgraph.fixation import mcclandish

mcclandish(1.0, 1.01, population_size=100)  # ~0.0179

The string alias is "mcclandish".

Spelling

The function and registry key are spelled mcclandish (one d), matching the v1 spelling.

Custom callables

add_model accepts any callable as model:

def my_model(fi, fj, **_):
    return (fj > fi).astype(float)   # 1.0 for advantageous, 0.0 otherwise

G.add_model(column="phenotypes", model=my_model)

The function should either:

  • Accept arrays. Receives two equal-length NumPy arrays of float64 source and target fitnesses; returns an array of the same shape. The array path is one numpy call per add_model. This is the fast path.
  • Accept scalars. Receives two floats; returns a float. add_model falls back to a Python for loop. Slower but correct.

If your callable raises TypeError on arrays, add_model automatically detects this and switches to the scalar loop.

Choosing a model

When you want... Use
The default, parameter-free trajectory analysis sswm
Edge weights proportional to relative fitness (not normalized) ratio
Population-size-dependent fixation, classic Moran formulation moran
Population-size-dependent fixation, exponentiated form mcclandish
Custom logic (e.g., enforce monotonicity) a callable

sswm is what gpgraph-v2's test suite and the streamlit demo use unless they explicitly call out a different model.

Numeric stability

All four built-in models use log-space decomposition to avoid overflow for large population_size or large fitness ratios. The boundary cases (f_j == f_i, population_size == 1, very large negative s_ij) are handled with the exact same branching as v1 so numerics agree at the seams.

If you see NaN or inf in G.edges[(i, j)]["prob"], check that:

  1. Your fitness column has no zeros for moran or mcclandish. Both require strictly positive fitnesses.
  2. Your fitnesses are not negative. SSWM, moran, and mcclandish all assume strictly positive fitness.
  3. population_size is >= 1.
